| Specifications |
| Camera |
| Image Sensor |
1/3” sensor |
| Min. Illumination |
0.014 lux @F1.4, AGC on
0 lux with IR |
| Shutter Speed |
1/25s ~ 1/100,000s |
| Lens |
2.8-12 mm @F1.4 |
| Angle of view: 113°-33.8° |
| Lens Mount |
Φ14 |
| Day & Night |
ICR |
| Digital Noise Reduction |
3D DNR |
| Wide Dynamic Range |
Digital WDR |
| Backlight compensation |
Yes,zone optional |
| Angle adjustment |
Pan: 0° - 355°, Tilt: 0° - 75°, Rotation: 0° - 355° |
| Compression Standard |
| Video Compression |
H.264 / MJPEG |
| H.264 codec profile |
Main profile |
| Bit Rate |
32 Kbps ~ 16 Mbps |
| Audio compression |
G.711/G.726/MP2L2 |
| Audio bit rate |
64Kbps(G.711) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
| Dual Stream |
Yes |
| Image |
| Max. Resolution |
1920×1080 |
| Frame Rate |
60Hz: 30fps (1920×1080)
50Hz: 25fps (1920×1080) |
| Image Settings |
Saturation, brightness, contrast adjustable through client software or web browser |
| ROI |
Yes, up to 4 configurable areas |
| Network |
| Network Storage |
NAS |
| Alarm Trigger |
Motion detection, Tampering alarm, Network disconnect, IP address
confict, Storage full , Storage error |
| Protocols |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,
NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
|
| System compatibility |
ONVIF, PSIA, CGI, ISAPI |
| General functionalities |
User Authentication, Watermark |
| Interface |
| Communication Interface |
1 RJ45 10 M / 100 M Ethernet interface |
| On-board Storage |
Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB |
| Audio Input/Output |
1/1 |
| Alarm Input/Output |
1/1 |
| General |
Working Temperature
/Humidity |
-22 °F ~ 140 °F(-30 °C ~ 60 °C )
Humidity 95% or less (non-condensing) |
| Power Supply |
DC12V±10% / PoE(802.3af) |
| Power Consumption |
Max. 5.5W |
| Impact protection |
IEC60068-2-75Eh, 50J; EN50102, up to IK10 |
| Ingress protection level |
IP66 |
| IR Range |
Up to 100ft(About 30m) |
| Dimension |
Φ5.5"×3.9"(Φ140.0 x 99.9mm) |
| Weight |
2.2lbs(1000g) |
|
